Ingesting Data from Kinesis to Delta Live Tables

To ingest data from Amazon Kinesis into a Delta Live Tables (DLT) Bronze layer, set up a streaming pipeline. It consumes data from Kinesis and writes it to Delta tables. Here’s a step-by-step guide.

1. Prerequisites

• AWS Configuration:
  • Ensure you have an active Amazon Kinesis data stream.
  • Your Databricks cluster must have the IAM role or access keys to access the Kinesis stream.
• Libraries:
  • Ensure your Databricks workspace includes the org.apache.spark:spark-sql-kinesis library or the Kinesis connector for Spark.
• DLT Pipeline:
  • Set up Delta Live Tables in your Databricks workspace.

---

2. Set Up Kinesis Stream Integration

To read data from Kinesis, you’ll use the readStream API. Below is an example configuration:

kinesis_config = {
    "streamName": "your-kinesis-stream-name",  # Replace with your Kinesis stream name
    "region": "your-region",  # e.g., us-east-1
    "awsAccessKeyId": "your-access-key-id",  # Or use instance profile for security
    "awsSecretKey": "your-secret-key",
    "startingPosition": "LATEST"  # Options: LATEST, TRIM_HORIZON, AT_TIMESTAMP
}

---

3. Define DLT Pipeline

You will define a Bronze layer table that reads from Kinesis and writes the raw data into a Delta table.

Bronze Layer Definition

import dlt
from pyspark.sql.functions import *

@dlt.table(
    name="bronze_kinesis_data",  # Table name
    comment="Raw data ingested from Kinesis",  # Description
    table_properties={"quality": "bronze"}  # Marking it as a Bronze layer
)
def bronze_table():
    return (
        spark.readStream
        .format("kinesis")
        .options(**kinesis_config)  # Pass Kinesis configurations
        .load()
    )

---

4. Process Data for Bronze Layer

If the incoming Kinesis data is in JSON format, you might want to parse it before saving:

@dlt.table(
    name="parsed_bronze_kinesis_data",
    comment="Parsed raw data from Kinesis"
)
def parsed_bronze_table():
    raw_data = dlt.read("bronze_kinesis_data")
    return raw_data.selectExpr("CAST(data AS STRING) AS raw_json")

---

5. Configure Pipeline Settings

• Auto Load Trigger:
  • Use trigger = {"interval": "10 seconds"} to define micro-batches for processing.
• Checkpoints:
  • DLT manages checkpoints automatically, but ensure your storage layer (e.g., DBFS) has enough space.

---

6. Pipeline Execution

• Create a Delta Live Table pipeline in Databricks:
  1. Navigate to Workflows > Delta Live Tables.
  2. Click Create Pipeline and provide:
     • Pipeline name.
     • Notebook path containing the above DLT script.
     • Enable Continuous Mode for streaming data.
  3. Configure the cluster settings and permissions.
  4. Start the pipeline.

---

7. Verify Data in the Bronze Layer

After running the pipeline, you can verify the ingested data:

SELECT * FROM bronze_kinesis_data;

---

8. Extend to Silver and Gold Layers

• Silver Layer: Clean and transform the data.
• Gold Layer: Aggregate or enrich the data for business use cases.

Example:

@dlt.table(
    name="silver_cleaned_data",
    comment="Cleaned Kinesis data",
    table_properties={"quality": "silver"}
)
def silver_table():
    return (
        dlt.read("parsed_bronze_kinesis_data")
        .filter("raw_json IS NOT NULL")
    )

---

Key Considerations

• Schema Evolution: Ensure the schema is adaptable if Kinesis data changes.
• Monitoring: Use Databricks UI to monitor pipeline execution and logs.
• Throughput: Kinesis streams have limits on throughput; monitor shard utilization.

This setup ensures that streaming data is reliably ingested from Amazon Kinesis. The data then moves into your Delta Live Tables Bronze layer for further processing.
